IQ8 Optical Smoke Detectors by ESSER
Optical smoke detector which works using the light scatter principle to guarantee safe and early detection of fire. Responds well to slow-burning, smouldering fires. Intelligent fire detector with decentralized intelligence, automatic function self-test, CPU failure mode, alarm and operating data memory, alarm indicator, soft-addressing and operating indication. The detector is provided with an integrated isolator. A remote indicator can be connected.

Part No.: 802371
Approval: VdS, BOSEC

IQ8 Optical Smoke Detectors by ESSER

SKU: 364215376135191
AED300.00Price
Color

  • Operating voltage                     : 8 ... 42 V DC

    Quiescent current @ 19 V DC   : approx. 50 μA

    Alarm current w/o communication curtain : approx. 18 mA

    Area to be monitored : max. 110 m²

    Height to be monitored : max. 12 m

    Air velocity : 0 ... 25.4 m/s

    Application temperature : -20 °C ... 72 °C

    Storage temperature : -25 °C ... 75 °C

    Type of protection : IP 40 (with base + option)

    Material : ABS plastic

    Air humidity : < 95 %

    Color : white, similar to RAL 9010

    Weight : approx. 110 g

    Detector specification : EN 54-7 / -17

    Dimensions : Ø: 117 mm H: 49 mm (62 mm incl. base)
